AIR 102 II 600 WH
Cod. 02013179
EAN 8422248109895
Product specifications
GENERAL INFORMATION
EAN/UPC
8422248109895
Subfamily
Conventional
Product sheet according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Annual energy consumption) (kWh/year)
60
EEI class (energy efficiency class)
D
FDE (fluid dynamic efficiency)
8,8
FDE class (fluid dynamic efficiency class)
E
LE (light efficiency) (lux/W)
13,1
LE class (light efficiency class)
D
GFE (grease filtering efficiency)
68
GFE class (grease filtering efficiency class)
D
Airflow in normal mode MIN (m3/h)
195
Airflow in normal mode MAX (m3/h)
320
Acoustic power in normal mode MIN (dB)
60
Acoustic power in normal mode MAX (dB)
67
Po (energy consumption in off mode) (W)
0
Ps (energy consumption in standby mode) (W)
0
Integration directive EU 66/2014
ƒ (time increase factor)
1,7
EEI (Energy Efficiency Index)
88,8
QBEP (maximum efficiency at air flow point) (m3/h)
191,2
PBEP (maximum efficiency at pressure point) (Pa)
136,9
WBEP (power consumption at maximum efficiency) (W)
83
WL (nominal power lighting system) (W)
11
EMIDDLE (Average illuminance on the cooking surface) (lux)
144
External Dimensions
Diamètre de sortie (mm)
120
Characteristics
Motor quantity
2
Motor model
L1
Maximum pressure (Pa)
221
Filter technology
Aluminium mesh
Control technology
Mechanical slider
Booster
-
Power levels
3
Timer
-
Filter saturation indicator
-
Charcoal filter replacement indicator
-
Dimmer function
-
Connectivity
No
Remote control
-
Display
-
Lighting
Light model
LED E-14
Ray technology
LED
Installation
Recirculation option
√
Charcoal filter
-
Back draught shutter
No
Inner shield
-
Electric connection
Nominal voltage (V)
220-240
Nominal frequency (Hz)
50
Nominal input power (W)
111
Electric shock protection
Class I
Power cord length (m)
0,7
Plug type
No plug
Accessories
Back draught shutter
02849002
Activated charcoal filter
02846764
